Image similar
Details
| Size | M 8 x 25 |
| Screw head | KN 1041 |
| Material | 19MnB4 hardening and tempering according to DIN EN ISO 898-1 Rm 1000 + 200 N/mm² |
| Surface | 5-7 µm, galvanised, blue tempered / transparent thick-layer passivated |
| Head diameter | 15.8 mm |
| Nominal diameter | 8 mm |
| Length | 25 mm |
| Hexolabular socket | T40 |
| Suitable for | BBG 86R, MBG 1210R, BBG 86R SASC, BBG 86R SASV, BBG 86R SC, BBG 86R SA, BBO 1210R, BBO 86R, MBO 1210R, KSG 1210KR, KSG 1210R, KLO 1208KR, KLO 1208R, KLO 1210KR, KLO 1210R, KSO 1210KR, KSO 1210R, ESD KLK 1208R, ESD KLK 1210R, GLT 1210/125R, GLT 1210/125RB, Wheel set suitable for Big boxes, suitable for Big boxes 120 x 80 and 120 x 100, RLGGV100x30P105x60 |
| Weight | 8 g |
